AWK-6222 User’s Manual Other Console Configurations
3-29
Transmission enhancement
Setting Description Factory Default
Enable/Disable This setting can enhance communication
b
y
strengthening the AWK-6222’s
transmission power. It is quite useful for
long-distance transmission or countering
environmental interference. Before enabling
this option you should carefully evaluate
and measure the transmission power of
whole system, and confirm that it is still
below regulatory limits.
Disable
NOTE
Make sure the same Transmission distance parameters are set in both AP and Client sides, and
both Master and Slave. When this parameter is more than 500, an optimal algorithm will be
enabled to support long-distance transmission.
Please note that Transmission enhancement only supports 802.11b/g mode; 802.11a mode is
not supported.
Transmission enhancement is also recommended to enable communication at both ends when
long-distance transmission is required. A high-gain antenna installed at a fixed antenna
connector can also improve performance. (Select Antenna at MAIN or AUX.)
Antenna
Setting Description Factory Default
Auto
The AWK-6222 uses four antennas (two MAIN
and two AUX) and enables the diversity
function for reducing multipath effect.
MAIN 1 and MAIN 2
Diversity function is disabled. Only MAIN 1
and 2 antenna is in use.
AUX 1 and AUX 2
Diversity function is disabled. Only AUX 1 and
2 antenna is in use.
Auto
EAPOL Version
Setting Description Factory Default
1 EAPOL version 1 is specified in the 2001
version of 802.1X, and is much more commonly
implemented.
2 EAPOL version 2 is specified in 802.1X-2004.
1
Turbo Roaming (for AP-Client operation mode's Client mode only)
Setting Description Factory Default
Enable/ Disable Moxa’s Turbo Roaming can enable rapid
handover when the AWK-6222, as a client,
roams among a group of APs.
Disable
