AWK-6222 User’s Manual Other Console Configurations
3-26
PEAP
There are a few differences in the inner authentication procedures for TTLS and PEAP. TTLS uses
the encrypted channel to exchange attribute-value pairs (AVPs), while PEAP uses the encrypted
channel to start a second EAP exchange inside of the tunnel. The AWK-6222 provides
MS-CHAP-V2 merely as an EAP method for inner authentication.
Inner EAP protocol
Setting Description Factory Default
MS-CHAP-V2 Microsoft CHAP version 2 is used MS-CHAP-V2
Anonymous
Setting Description Factory Default
Max. 31 characters A distinct name used for outer
authentication
None
User name & Password
Setting Description Factory Default
User name and password used in
inner authentication
None
