AWK-6222 User’s Manual Other Console Configurations
3-7
Current local time
Setting Description Factory Default
User adjustable time
The date and time parameters allow
configuration of the local time with
immediate activation.
None
(yyyy/mm/dd hh:mm:ss
format; 24-hour format.)
Time zone
Setting Description Factory Default
User selectable time
zone
The time zone setting allows
conversion from GMT (Greenwich
Mean Time) to local time.
GMT (Greenwich Mean
Time)
ATTENTION
Changing the time zone will automatically adjust the Current local time. You should configure
the Time zone before setting the Current local time.
Daylight saving time
Setting Description Factory Default
Enable/ Disable
Daylight saving time (also know as
DST or summer time) involves
advancing clocks (usually 1 hour)
during the summer time to provide
an extra hour of daylight in the
afternoon.
Disable
When Daylight saving time is enabled, the following parameters can be shown:
y The Starts at parameter allows users to enter the date that daylight saving time begins.
y The Stops at parameter allows users to enter the date that daylight saving time ends.
y The Time offset parameter indicates how many hours forward the clock should be advanced.
Time server 1/ 2
Setting Description Factory Default
The 1st/ 2nd time server
IP/Name
IP or Domain address of NTP time
server. The 2nd time will be used if
the 1st NTP server fails to connect.
None
Query period
Setting Description Factory Default
Query period time
(1- 9999 seconds)
This parameter determines how often
the time is updated from the NTP
server.
600 (seconds)
