AWK-6222 User’s Manual Other Console Configurations

3-10

The following figure shows the Wireless Redundancy operation mode:

WLAN Operation mode

Setting Description Factory Default

Redundant AP

AP with Dual RF redundancy

capable of serving dual RF clients.

Redundant Client

Dual RF redundant clients can join

dual RF redundant APs.

Redundant AP
