AWK-6222 User’s Manual Other Console Configurations

3-19

Key type

Setting Description Factory Default

HEX

Specifies WEP keys in hex-decimal

number form

ASCII Specifies WEP keys in ASCII form

HEX

Key length

Setting Description Factory Default

64 bits

Uses 40-bit secret keys with 24-bit

initialization vector

128 bits

Uses 104-bit secret key with 24-bit

initialization vector

64 bits

Key index

Setting Description Factory Default

1-4 Specifies which WEP key is used Open

WEP key 1-4

Setting Description Factory Default

ASCII type:

64 bits: 5 chars

128 bits: 13chars

HEX type:

64 bits: 10 hex chars

128 bits: 26 hex chars

A string that can be used as a WEP

seed for RC4 encryption engine.

None
