AWK-6222 User’s Manual Other Console Configurations
3-22
WPA Type
Setting Description Factory Default
Personal
Provides Pre-Shared Key-enabled
WPA and WPA2
Enterprise
Provides enterprise-level security
for WPA and WPA2
Personal
Encryption method
Setting Description Factory Default
TKIP
Temporal Key Integrity Protocol is
enabled
AES
Advance Encryption System is
enabled
Mixed*
Provides TKIP broadcast key and
TKIP+AES unicast key for some
legacy AP clients. This option is
rarely used. *This option is
available in Redundant AP, AP, or
Master mode only, and cannot
support AES-enabled clients.
TKIP
Primary/ Secondary RADIUS server IP
Setting Description Factory Default
The IP address of
RADIUS server
Specifies the delegated RADIUS
server for EAP
None
Primary/ Secondary RADIUS port
Setting Description Factory Default
Port number
Specifies the port number of the
delegated RADIUS server
1812
Primary/ Secondary RADIUS shared key
Setting Description Factory Default
Max. 31 characters
The secret key shared between AP
and RADIUS server
None
Key renewal
Setting Description Factory Default
60 – 86400 seconds
(1 minute to 1 year)
Specifies the time period of group
key renewal
3600 (seconds)
