IDE Channel 0/1/2/3/4/5 Master & IDE Channle 0/1 Slave
Leave this item at Auto to enable the system to automatically detect and
configure IDE devices on the channel. If it fails to find a device, change the
value to Manual and then manually configure the drive by entering the
characteristics of the drive in the items described below.
Note: Before attempting to configure a hard disk drive, ensure that you have the
configuration information supplied by the manufacturer of your hard drive.
Incorrect settings can result in your system not recognizing the installed hard
disk.
Access Mode
This item defines ways that can be used to access IDE hard disks such as LBA
(Large Block Addressing). Leave this value at Auto and the system will automatically
decide the fastest way to access the hard disk drive.
Press <Esc> to return to the Standard CMOS Features page.
Drive A [1.44M, 3.5in.]
These items define the characteristics of any diskette drive attached to the system.
You can connect one or two diskette drives.
IDE HDD Auto-Detection
Press <Enter> while this item is highlighted to prompt the Setup Utility to automatically
detect and configure an IDE device on the IDE channel.
Note: If you are setting up a new hard disk drive that supports LBA mode, more than one
line will appear in the parameter box. Choose that lists LBA for an LBA drive.
Halt On [All, But Keyboard]
This item defines the operation of the system POST (Power On Self Test) routine.
You can use this item to select which types of errors in the POST are sufficient to
halt the system.
Base Memory, Extended Memory and Total Memory
These items are automatically detected by the system at start up time. These are
display-only fields. You cannot make chanages to these fields.
Video [EGA/VGA]
Thsi item defines the video mode of the system. This motherboard has a built-in
VGA graphics system; you must leave this item at the default value.
Floppy 3 Mode Select [Disabled]
Floppy 3 mode refers to a 3.5-inch diskette with a capacity of 1.2 MB. Floppy 3
mode is sometimes used in Japan.
