Italiano
Indice delle caratteristiche
CPU
Chipset
• Processore MCP per media e comunicazioni NVIDIA
®
nForce4 SLI
Memoria
Opzioni
d’espansione
• 2 x slots PCI Express x16 (Modalità SLI: x8+x8; modalità x8
per PCI-E singolo)
• 1 x slot PCI Express x1
• 3 x slots PCI
Deposito
• Supportata da nForce4 SLI
- Funziona in modalità Gen1i (1,5 Gb/s) o Gen2i (3,0 Gb/s)
- 4 dispositivi SATA II Gen 1 o Gen 2
-configurazione RAID 0, RAID 1, RAID 0+1
• Supportato da SiI3132
- Velocità di trasferimento di Generation 2 ATA seriale di 3,0
Gb/s
- 2 x dispositivi SATA II
-configurazione RAID 0, RAID 1
IEEE 1394a
• Controller IEEE 1394a TI TSB43AB22A
• Supporto di 2 porte per cavo IEEE1394a a 100M bit/s, 200M
bit/s e 400M bit/s
Audio
• CODEC audio a 8 canali Realtek ALC850
• Conforme alla specifica AC’97 2.3
Doppia LAN
• Controller LAN 10/100 Mbps Realtek RTL8100C
• PHY LAN Giga Marvell 88E1111
Pannello
posteriore
I/O
• 1 x porta per tastiera PS/2
• 1 x connettore mouse PS/2
• 4 x porte USB
• 2 x connettori RJ45 LAN
• 1 x porta Seriale (COM1)
• 2 uscite SPDIF (ottica e coassiale) digitali
• 1 jack Audio (porte Line-in, Line-out e Mic-in)
• Presa 939 per CPU AMD Athlon 64/Athlon 64 FX
• Interfaccia CPU HyperTransport a elevate prestazioni
• Velocità di trasferimento di 2000/1600/1200/800/400 MT/s
• Dual-channel DDR memory architecture
• 4 prese DIMM per DDR SDRAM da 2,5 V a 184 pin con
supporto di fino a 4 GB
• Supporto di DDR SDRAM DDR400/333/266/200 senza
buffer
Caratteristic-
he BIOS
• BIOS Award con 4Mb Flash ROM
• Supporta Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
• Supporta specifiche di revisione ACPI 1.0B
