Résumé des caractéristiques
CPU
Chipset
• Processeur multimédia et de communications (MCP)
NVIDIA
®
nForce4 SLI
Mémoire
Options
d’extension
• 2 x logements PCI Express x16 (Mode SLI : x8+x8, simple
PCI-E est mode x8)
• 1 x logement PCI Express x1
• 3 x logements PCI
Stockage
• Pris en charge par nForce4 SLI
- Fonctionne en mode Gen1i (1,5Gb/s) ou Gen2i (3,0Gb/s)
- 4 x périphériques SATA II Gen 1 ou Gen 2
- Configuration RAID 0, RAID 1, RAID 0+1
• Pris en charge par SiI3132
- Vitesse de transfert ATA Série Génération 2 de 3,0Gb/s
- 2 x périphériques SATA II
- Configuration RAID 0, RAID 1
IEEE 1394a
• Contrôleur IEEE1394a TI TSB43AB22A
• Prend en charge 2 ports de câble x IEEE1394a à 100M bits/s,
200M bits/s, et 400M bits/s
Audio
• CODEC audio Realtek ALC850 8 canaux
• Conforme aux spécifications AC’97 2,3
LAN Double
• Contrôleur LAN Realtek RTL8100C 10/100 Mbps
• Marvell 88E1111 Giga LAN PHY
E/S du
panneau
arrière
• 1 x clavier PS/2
• 1 x connecteur souris PS/2
• 4 x ports USB
• 2 x connecteurs LAN RJ45
• 1 x port Série (COM1)
• 2 x sorties SPDIF numériques (Optique & Coaxiale)
• 1 x prise Audio (Ports d’entrée de ligne, sortie de ligne,
entrée Micro)
• Socket 939 pour processeur AMD Athlon 64/Athlon 64 FX
• Interface de CPU HyperTransport de Hautes Performances:
• Vitesse de transfert de 2000/1600/1200/800/400 MT/s
• Architecture mémoire DDR double canal
• 4 x sockets DIMM SDRAM DDR, 2.5V, 184 broches
prenant en charge jusqu’à 4 Go
• Prend en charge les SDRAM DDR sans mémoire tampon
DDR400/333/266/200
Caractéristi-
ques du BIOS
• Award BIOS avec ROM Flash de 4Mb
• Prend en charge Plug & Play 1.0A, APM 1.2, Multi Boot, DMI
• Prend en charge les spécifications 1.0B révision ACPI
