ECS Elitegroup KN1 SLI Extreme [69/88] 特徴概要
![ECS Elitegroup KN1 SLI Extreme [69/88] 特徴概要](/views2/1212430/page69/bg45.png)
日本語
特徴概要
プロセッサ
チップセット
• NVIDIA
®
nForce4 SLI メディアおよび通信プロセッサ
(MCP)
メモリ
拡張スロット
• 2つのPCI Express x16スロット(SLI モード: x8+x8、た
だし、単一の PCI-Eの場合は x8 モード)
• 1つのPCI Express x1スロット
• 3つのPCI スロット
保存装置
• nForce4 SLI チップセットでサポートするのは
- Gen1i (1.5Gb/秒) やGen2i (3.0Gb/秒) モードでの動
作が可能
- SATA II Gen 1 または Gen 2 の装置が4つまで接続
可能
- RAID 0、RAID 1、および RAID 0+1の 構成
• SiI3132でサポートするのは
- Serial ATA Generation 2 で3.0 Gb/秒の転送率を
実現
- 2つのSATA デバイス
- RAID 0、 RAID 1の 構成
IEEE 1394a
• TI TSB43AB22A IEEE1394a コントローラ
• IEEE1394a ケーブルポートが2つで、100M bits/s,
200M bits/s, および400M bits/sの転送率に対応
オーディオ
• Realtek ALC850 8チャネルオーディオCODEC
• AC’97 2.3 規格に準拠
デュアルLAN
• Realtek RTL8100C 10/100 Mbps LAN コントローラ
• Marvell 88E1111 Giga LAN PHY
背面パネル入
出力
• PS/2 コネクタが1つ
• PS/2 マウスコネクタが1つ
• USBポートが4つ
• RJ45 LAN コネクタが2つ
• シリアルポート(COM1)が1つ
• デジタルSPDIF (光ファイバ式と同軸ケーブル式に対
応) 出力が2つ
• オーディオジャック(ライン入力、ライン出力、およびマ
イクロホン入力のポート)が1式
• AMD Athlon 64/Athlon 64 FX CPUのSocket 939を
搭載
• 高性能HyperTransport CPU インターフェースに対応
• 2000/1600/1200/800/400 MT/s転送率を実現
• デュアルチャネルDDRメモリのアーキテクチャ
• 184ピン2.5V仕様のDDR SDRAM DIMM ソケットを4つ
搭載し、それに最大4 GBまでのメモリを装着可能
• DDR400/333/266/200 非バッファDDR SDRAMに対応
BIOSの諸
機能
• 4 Mb Flash ROM のAward BIOS
• Plug&Play 1.0A、APM 1.2、Multi Boot、および
DMIをサポート
• ACPI revision 1.0B 規格に準拠
