Memory
1.3 Feature Summary
CPU
Chipset
• NVIDIA
R
nForce4 SLI media and communications
processor (MCP)
IEEE 1394a
• TI TSB43AB22A IEEE1394a controller
• Supports 2 x IEEE1394a cable ports at 100M bits/s,
200M bits/s, and 400M bits/s
Audio
• Realtek ALC850 8-channel audio CODEC
• Compliant with AC’97 2.3 specification
• Socket 939 for AMD Athlon 64/Athlon 64 FX CPU
• High-performance HyperTransport CPU Interface
• Transfer rate of 2000/1600/1200/800/400 MT/s
• Dual-channel DDR memory architecture
• 4 x 184-pin, 2.5V, DDR SDRAM DIMM sockets support
up to 4 GB
• Support DDR400/333/266/200 unbuffered DDR
SDRAM
Expansion
Slots
• 2 x PCI Express x16 slots (SLI mode: 8x+8x; single
PCI-E is 8x mode )
• 1 x PCI Express x1 slot
• 3 x PCI slots
• Supported by nForce4 SLI
- Operate at Gen1i (1.5Gb/s) or Gen2i (3.0Gb/s) mode
- 4 x SATA II Gen 1 or Gen 2 devices
- RAID 0, RAID 1, RAID 0+1 configuration
• Supported by SiI3132
- Serial ATA Generation 2 transfer rate of 3.0 Gb/s
- 2 x SATA II devices
- RAID 0 and RAID 1 configuration
Storage
Dual LAN
• Realtek RTL8100C 10/100 Mbps LAN controller
• Marvell 88E1111 Giga LAN PHY
Rear panel
I/O
• 1 x PS/2 keyboard connector
• 1 x PS/2 mouse connector
• 4 x USB ports
• 2 x RJ45 LAN connectors
• 1 x Serial port (COM1)
• 2 x Digital SPDIF (Optical & Coaxial) out
• 1 x Audio jack (microphone, line-in, and 8-channel line
out)
BIOS features
• Award BIOS with 4Mb Flash ROM
• Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
• Supports ACPI revision 1.0B specificaion
