Deutsch
Zusammenfassung der Merkmale
CPU
Chipsatz
• NVIDIA
®
nForce4 SLI Media- und Kommunikationsprozessor
(MCP)
Arbeitsspeicher
Erweiter-
ungsmöglich
-
keiten
• 2 x PCI Express x16 Steckplätze (SLI-Modus: x8+x8, Einzel-PCI-E:
x8 Modus)
• 1 x PCI Express x1 Steckplät
• 3 x PCI Steckplätze
Speicher
• Unterstützt durch nForce4 SLI
- Betrieb im Gen1i- (1.5Gb/s) oder Gen2i- (3.0Gb/s) Modus
- 4 x SATA II Gen 1- oder Gen 2-Geräte
- RAID 0, RAID 1, RAID 0+1 Konfiguration
• Unterstützt durch einen SiI3132
-Serial ATA Generation 2, Transferrate von 3.0 Gb/s
-2 x SATA II Geräte
-RAID 0, RAID 1 Konfiguration
IEEE 1394a
• TI TSB43AB22A IEEE1394a Controller
• Unterstützt 2 x IEEE1394a Kabelports mit 100M bits/s, 200M bits/s
und 400M bits/s
Audio
• Realtek ALC850 8-Kanal Audio-CODEC
• Entspricht AC’97 2.3 Spezifikation
Dual LAN
• Realtek RTL8100C 10/100 Mbps LAN-Controller
• Marvell 88E1111 Giga LAN PHY
Rear panel
I/O
• 1 x PS/2 Tastatur
• 1 x PS/2 Mausanschluss
• 4 x USB Anschlüsse
• 2 x RJ45 LAN Anschlüsse
• 1 x Seriellanschluss (COM1)
• 2 x Digital SPDIF- (Optisch & Coaxial) out
• 1 x Audiobuchse (Line-in, Line-out und Mic-in Ports)
• Socket 939 für AMD Athlon 64/Athlon 64 FX CPU
• Hochleistungsfähiges HyperTransport CPU-Interface
• Transferrate von 2000/1600/1200/800/400 MT/s
• Dual-Kanal DDR Speicherarchitektur
• 4 x 184-Pin, 2.5V, DDR SDRAM DIMM-Sockets unterstützen bis
zu 4 GB
• Unterstützt ungepufferte DDR400/333/266/200 DDR SDRAM
BIOS
Merkmale
• Award BIOS mit 4Mb Flash ROM
• Unterstützt Plug und Play 1.0A, APM 1.2, Multi Boot, DMI
• Unterstützt ACPI Revision 1.0B Spezifikation
