![ECS Elitegroup KN1 SLI Extreme [38/88] Onboard device press enter](/img/pdf.png)
ECS Elitegroup KN1 SLI Extreme [38/88] Onboard device press enter
![ECS Elitegroup KN1 SLI Extreme [38/88] Onboard device press enter](/views2/1212430/page38/bg26.png)
3-11
Onchip USB (V1.1+V2.0)
This item enables users to enable or disable the onchip USB function, setting it to be
USB1.1 or USB2.0 compatible.
USB Keyboard Support (Enabled)
Enables this item if you plan to use a keyboard connected through the USB port in
a legacy operating system (such as DOS) that does not support Plug and Play.
USB Mouse Support (Enabled)
Enables this item if you plan to use a mouse connected through the USB port in a
legacy operating system (such as DOS) that does not support Plug and Play.
Onboard Device (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
OnChip USB [V1.1+V2.0V]
USB Keyboard Support [Enabled]
USB Mouse Support [Enabled]
AC97 Audio [Auto]
Onboard Giga Lan [Enabled]
Onboard PCI-Exp Raid [Disabled]
Onboard PCI 1394 [Enabled]
Onboard Lan [Enabled]
Onboard Lan Boot ROM [Disabled]
Item Help
Menu Level
Phoenix-AwardBIOS CMOS Setup Utility
Onboard Device
F5:Previous Values F6:Performance Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
AC97 Audio (Auto)
Enables and disables the onboard audio chip. Disable this item if you are going to
install a PCI audio add-in card.
Onboard Giga Lan (Enabled)
Enables or disables the onboard Giga Lan function.
Onboard PCI-Exp Raid (Disabled)
Enables or disables the onboard PCI-Exp Raid function.
Onboard PCI 1394 (Enabled)
Enables or disables the onboard 1394 function.
Onboard LAN (Auto)
Enables or disables the onboard LAN function.
Onboard Lan Boot ROM (Enabled)
Enables or disables the onboard Lan boot rom function.
Press <Esc> to return to the Integrated Peripherals page.
