Česky
Souhrn vlastností
CPU
Čipová sada
• Procesor pro ovládání médií a komunikaci NVIDIA
®
nForce4 SLI (MCP)
Paměť
Rozšiřující
sloty
• 2 x slot PCI Express x16 (Režim SLI: x8+x8, jednoduchý režim
PCI-E je x8)
• 1 x slot PCI Express x1
• 3 x slot PCI
Disková
zařízení
• Podporovaná nForce4 SLI
- Provoz v režimu Gen1i (1,5 Gb/s) nebo Gen2i (3,0 Gb/s)
- 4 x zařízení SATA II Gen 1 nebo Gen 2
- Konfigurace RAID 0 , RAID 1, RAID 0+1
• Podporovaná SiI3132
- Serial ATA Generation 2 s přenosovou rychlostí 3,0 Gb/s
- 2 x zařízení SATA II
- Konfigurace RAID 0, RAID 1
IEEE 1394a
• Řadič TI TSB43AB22A IEEE 1394a
• Podpora 2 kabelových portů IEEE 1394a s přenosovou rychlostí
100 Mb/s, 200 Mb/s a 400 Mb/s
Zvuk
• 8kanálový zvukový kodek Realtek ALC850
• Splňuje požadavky standardu AC’97 2.3
Duální LAN
• Řadič sítě 10/100 Mbps LAN, Realtek RTL8100C
• Řadič gigabitové sítě LAN, Marvell 88E1111 PHY
Vstupy/
výstupy
na zadním
panelu
• 1 x konektor klávesnice PS/2
• 1 x konektor myši PS/2
• 4 x port USB
• 2 x konektor LAN RJ45
• 1 x sériový port (COM1)
• 2 x digitální výstup SPRIT (optický a koaxiální)
• 1 x zvukový konektor (linkový vstup/linkový výstup/mikrofon)
• Patice 939 pro procesory AMD Athlon 64/Athlon 64 FX
• Vysoce výkonné rozhraní HyperTransport CPU
• Přenosové rychlosti 2000/1600/1200/800/400 MT/s
• Dvojkanálová paměťová architektura DDR
• 4 x 184kolíková patice DDR SDRAM DIMM 2,5 V, podporující
paměť do kapacity až 4 GB
• Podpora pamětí typu DDR SDRAM 400/333/266/200, bez
vyrovnávací paměti
Vlastnosti
BIOS
• Award BIOS s 4 Mb Flash ROM
• Podpora Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
• Podpora standardu ACPI verze 1.0B
