Polski
Cechy
CPU
Chipset
• Procesor Media & Communications (MCP) NVIDIA
®
nForce4
SLI
Pamięć
Możliwości
rozbudowy
• 2 złącze PCI Express x16(Tryb SLI: x8+x8, pojedyńcze PCI-E
pracuje w trybie x8)
• 1 złącza PCI Express x1
• 3 złącza PCI
Urządzenia
pamięc
masowej
• Obsługiwane przez nForce4 SLI
- Pracuje w trybie Gen1i (1.5Gb/s) lub Gen2i (3.0Gb/s)
- Urządzenie w standardzie 4 x SATA II Gen 1 lub Gen 2
- Konfiguracje
RAID 0, RAID 1, RAID 0+1
• Obsługiwane przez SiI3132
- Serial ATA 2 generacji o zdolności przesyłania danych 3.0 Gb/s
- 2 urządzenia SATA II
- Konfiguracje RAID 0, RAID 1
IEEE 1394a
• Kontroler TI TSB43AB22A IEEE1394a
• Obsługuje 2 złącza IEEE1394a o szybkości 100M bit/s,
200M bit/s i 400M bit/s
Audio
• 8-kanałowy audio CODEC Realtek ALC850
• Zgodne z AC’97 2.3
Dual LAN
• Kontroler LAN Realtek RTL8100C 10/100 Mbps
• Marvell 88E1111 Giga LAN PHY
Gniazda We/
Wy na tylnym
panelu
• 1 gniazdo klawiatury PS/2
• 1 gniazdo myszy PS/2
• 4 gniazda USB
• 2 złącza RJ45 LAN
• 1 port szeregowy (COM1)
• 2 gniazda Digital SPDIF (wyjście optyczne i koaksialne)
• 1 złącze audio (gniazda wejściowe i wyjściowe audio, gniazdo
wejściowe mikrofonowe)
• Gniazdo 939 dla procesorów AMD Athlon 64/Athlon 64 FX
CPU
• Złącze szybkiego transpotu danych HyperTransport CPU Inter-
face
• Szybkość przesyłania danych 2000/1600/1200/800/400 MT/s
• Architektura pamięci dwukanałowej DDR
• 4 184-nóżkowe złącza 2.5V, DDR SDRAM DIMM obsługujące
do 4 GB pamięci
• Obsługa pamięci typu DDR400/333/266/200 i niebuforowanej
pamięci DDR SDRAM
Cechy BIOSu
• Award BIOS, zaopatrzony w 4Mb Flash ROM
• Obsługuje technologie Plug and Play 1.0A, APM 1.2, Multi Boot,
DMI
• Obsługuje technologię ACPI w wersji 1.0B
