3-16
Press <Esc> to return to the main BIOS setting page.
PCI/VGA Palette Snoop [Disabled]
This item is designed to overcome problems that can be caused by some non-
standard VGA cards. This board includes a built-in VGA system that does not require
palette snooping so you must leave this item disabled.
Maximum Payload Size [4096]
This item specifies the maximum payload size for the PCI Express function.
3.3-7 PC Health Status
On motherboards that support hardware monitoring, this item lets you
monitor the parameters for critical voltages, temperatures and fan speeds.
Phoenix-AwardBIOS CMOS Setup Utility
PC Health Status
Shutdown Temperature [Disabled]
CPU Vcore Voltage 1.34V
Vcc 3V 3.29V
Vcc 2.5V 2.57V
Vcc 1.5V 1.47V
Vcc 1.2V 1.16V
Vcc +12V 10.49V
Vcc 5V 4.81V
Voltage Battery 3.18V
System Temperature 32
o
C
CPU Temperature 49
o
C
CPUFAN1 Speed 2481 RPM
NBFAN1 Speed 6250 RPM
CASFAN1 Speed 0 RPM
CASFAN2 Speed 0 RPM
Power 20/24Pin Message [Enabled]
Item Help
Menu Level
F5:Previous Values F6:Performance Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Shutdown Temperature [Disabled]
Enables you to set the maximum temperature the system can reach before powering
down.
System Component Characteristics
These fields provide you with information about the systems current operating
status. You cannot make changes to these fields.
Power 20/24Pin Message [Enabled]
This item enables or disables the Power cable 20/24 Pin Message show up.
