简体中文
• 1 个 24 针 ATX 电源接口和 1 个 4 针 12 V 接口
• 1 个 4 针 ATX4P1 电源接口
• 1 个软驱接口- 支持 360K ~ 2.88M 字节，3 Mode
FDD 或 LS120
• 2 个 IDE 接口
• 6 个串行 ATA 接口
• 3 个 USB 2.0 接头，支持另外 6 个 USB 端口
• 2 个 1394a 接头
• 1 个 LPT1 接头
• 1 个 前面板开关/LED 接头
• 1 个 前面板音频接头
• 1 个 红外接口
• 1 个 SPK1接口
• 1 个 CD-in接口
• CPUFAN1/NBFAN1/CASFAN1~3 接口
• ATX 尺寸
• 305mm x 244mm
外形
集成 I/O
