3-5
Hard Disk Boot Priority
Scroll to this item and press <Enter> to view the following screen:
Phoenix-AwardBIOS CMOS Setup Utility
Hard Disk Boot Priority
3.3-2 Advanced BIOS Features
This option defines advanced information about your system.
Hard Disk Boot Priority [Press Enter]
CPU Internal Cache [Enabled]
External Cache [Enabled]
Quick Power On Self Test [Enabled]
First Boot Device [Floppy]
Second Boot Device [Hard Disk]
Third Boot Device [CDROM]
Boot Other Device [Enabled]
Swap Floppy Drive [Disabled]
Boot Up Floppy Seek [Disabled]
Boot Up NumLock Status [On]
Gate A20 Option [Fast]
ATA 66/100 IDE Cable Msg. [Enabled]
Typematic Rate Setting [Disabled]
Typematic Rate (Chars/Sec0 6
Typematic Delay (Msec) 250
Security Option [Setup]
APIC Mode [Enabled]
Item Help
Menu Level
Phoenix-AwardBIOS CMOS Setup Utility
Advanced BIOS Features
X
X
F5:Previous Values F6:Performance Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
All processors that can be installed in this motherboard use CPU internal cache
memory to improve performance. Leave this item at the default value for better
performance.
CPU Internal Cache (Enabled)
External Cache (Enabled)
Users can enable this item to improve the system performance. Leave this item at
the default value for better performance.
Quick Power On Self Test (Enabled)
Enable this item to shorten the power on testing (POST) and have your system start
up faster. You might like to enable this item after you are confident that your system
hardware is operating smoothly.
1. Ch0 M : WDC WD800BB-22FJA0
2. Bootable Add-in Cards
Item Help
Menu Level
Use < > or < > to
select a device, then press
<+> to move it up, or <-> to
move it down the list. Press
<ESC> to exit this menu.
: Move PU/PD+/-/:Change Priority F10:Save ESC:Exit
