Česky
• 1x 24kolíkový napájecí konektor ATX a 4kolíkový konektor 12 V
• 1x 4kolíkový napájecí konektor ATX4P1
• 1x konektor floppy diskových mechanik – podpora 360 kB až 2,88
MB, 3 režimy FDD nebo LS120
• 2x konektor IDE
• 6x konektor Serial ATA
• 3x rozhraní USB 2.0 s podporou dalších 6 USB portů
• 2x rozhraní 1394a
• 1x rozhraní LPT1
• 1x rozhraní pro spínač na předním panelu/LED
• 1x rozhraní pro zvukový vstup/výstup na předním panelu
• 1x infračervené rozhraní
• 1x rozhraní SPK1
• 1x vstup CD
• Konektory CPUFAN1/NBFAN1/CASFAN1~3
• Rozměry standardu ATX
• 305mm x 244mm
Velikost
Interní
vstupy/
výstupy
