• Un conector cu 24 ace pentru alimentare cu energie şi conector de
12 V cu 4 ace
• Un conector reţea electrică 4-pin ATX4P1
• Un conector Floppy, pentru dischete de 360 KB–2,88 MB, FDD
cu 3 moduri sau LS120
• Două sloturi IDE
• Şase conectoare ATA seriale
• Trei conectoare USB 2.0, cu posibilitate pentru alte 6 porturi USB
• Două conectoare 1394a
• Un conector LPT1
• Un comutator/conector LED pe panoul frontal
• Un conector audio pe panoul frontal
• Un Infrared header
• Un SPK1 header
• Un CD-in header
• Conectoare CPUFAN1/NBFAN1/CASFAN1~3
• Dimensiuni ATX
• 305mm x 244mm
