Română
Sumarul caracteristicilor
Unitatea
centrală (CPU)
Set de chipuri
• Procesor de media şi comunicaţii (MCP) NVIDIA
®
nForce4 SLI
Memorie
Sloturi de
extindere
• Două sloturi PCI Express de 16x (Mod SLI: x8+x8, PCI-E-ul
singular este în mod x8)
• Un slot PCI Express de 1x
• Trei sloturi PCI
Stocare
• Compatibilă cu nForce4 SLI
- Moduri de operare: Gen1i (1.5Gb/s) sau Gen2i (3.0Gb/s)
- 4 echipamente SATA II Gen 1 sau Gen 2
- Configuraţie RAID 0, RAID 1 şi RAID 0+1
• Compatibilă cu SiS180
- Serial ATA, generaţia 2-a, cu o rată de transfer de 3.0 Gb/s
- Două unităţi SATA II devices
- Configuraţie RAID 0 şi RAID 1
IEEE 1394a
• Controler TI TSB43AB22A IEEE1394a
• Funcţionează cu 2 porturi de cablu IEEE1394a la viteze de
100 Mbiţi/s, 200 Mbiţi/s şi 400 Mbiţi/s
Audio
• CODEC audio Realtek ALC850 cu 8 canale
• Compatibil cu specificaţia AC’97 2.3
LAN dual
• Controler LAN Realtek RTL8100C 10/100 Mbps
• Marvell 88E1111 Giga LAN PHY
I/O de pe
panoul din
spate
• O tastatură PS/2
• Un conector de mouse PS/2
• Patru porturi USB
• Două conectoare LAN RJ45
• Un port serial (COM1)
• Două ieşiri SPDIF digitale (optică şi coaxială)
• O mufă audio (cu porturi de intrare, ieşire şi pentru microfon)
• Soclu 939 pentru unităţi centrale (CPU) AMD Athlon 64/Athlon
64 FX
• Interfaţă CPU HyperTransport de înaltă performanţă
• Viteză de transfer de 2000/1600/1200/800/400 MT/s
• Architectură cu module de memorie DDR cu canal dual
• 4 socluri DDR SDRAM DIMM de 2,5 V şi 184 ace, cu
capacitate maximă de 4 GB
• Suport pentru module DDR SDRAM
DDR400/333/266/200 fără zonă tampon
Caracteristici
BIOS
• Award BIOS cu Flash ROM de 4 Mb
• Compatibil cu Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
• Compatibil cu ACPI, versiunea 1.0B
