ECS Elitegroup KN1 SLI Extreme [74/88] 主機板尺寸

繁體中文

• 1個24針ATX 電源供應器連接器及4針12 V 連接器

• 1個 4針ATX4P1 電源連接器

• 1個軟碟機連接器，可支援360K至2.88M位元組之3

Mode 軟碟機及LS120軟碟機

• 2個IDE連接器

• 6個序列ATA 連接器

• 3個USB 2.0接頭，可支援6個額外的USB埠

• 2個1394a接頭

• 1個LPT1接頭

• 1個前面板開關及1個LED 接頭

• 1個前面板音訊接頭

• 1個紅外線接頭

• 1個SPK1接頭

• 1個CD-in接頭

• CPUFAN1/NBFAN1/CASFAN1~3連接器

• ATX 尺寸

• 305mm x 244mm

主機板尺寸

內部輸出入

介面
