Unit 1
Interface
CNC
(Customer Supplied)
041993
CONTROL BOARD
1 2 3 4
S100
43
J303
21 2 3 41
J300A J300B
CNC Interface Cable
J300A
S100
J300B
J303
CONTROL BOARD
Unit 2
J300A
S100
J300B
J303
CONTROL BOARD
Unit 3
J300A J300B
S100
J303
CONTROL BOARD
Unit 4
CNC Interface CableCNC Interface Cable CNC Interface Cable
Serial ID
Dipswitch
Machine Motion
Jumper Block
Jumper Block
Machine Motion
Dipswitch
Serial ID
Jumper Block
Machine Motion
Dipswitch
Serial ID
Jumper Block
Machine Motion
Dipswitch
Serial ID
J106
21
J107
1 2
J106
1 2 1 2
J107 J106
1 2 1 2
J107 J106
1 2 1 2
J107
Notes:
1) For single system installations set Serial ID (S100), and Machine Motion (J303) as shown in Unit 1,
jumpers J106 and J107 must be closed.
2) On multi-system installations refer to the illustration.
Jumpers J106 and J107 are left open on all systems except for the very last system where they are in the closed position.
Termination resistors (120-ohm) or termination jumpers must be installed/set at the CNC for
each of the RS-422 RX and TX signal pairs.
3) If a Hypertherm Automation Controller is being used, and there are intermittent communication failures (PS Link Failure),
try removing the jumpers on J106 and J107 on the control board, and the termination jumper (J6 or J8) on the
serial isolation board in the controler. Only remove the termination jumper on the serial isolation board that is
connected to the HPR power supply. See sheet 17 for more details.
Optional Multi-System Interface
5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4
S101
ON
041993
1 2 3 4
S101
ON
041993
1 2 3 4
S101
ON
041993
1 2 3 4
S101
ON
4321 2 3 41
4321 2 3 41
4321 2 3 41
HPR PAC
Dry Cutting System
HPR PAC
Dry Cutting System
HPR PAC
Dry Cutting System
HPR PAC
Dry Cutting System
4 3 2 1
1
A
4 3 2
A
B
C
D
B
C
D
120
RX
Termination Termination
120
TX
ELEC SCH:HPR130XD POWER SUPPLY
D
013375
SHEET 16 OF 19
Switch 1 is in the On position
Switches 2-8 are in the Off position
S301
1 2 3 4 5 6 7 8
Dipswitch setting example:
21 3 4
5 6 7 8
ON
ON
