Asus ROG ZENITH EXTREME [23/104] Expansion slots

ROG ZENITH EXTREME

1-7

Chapter 1

1.1.5 Expansion slots

Unplugthepowercordbeforeaddingorremovingexpansioncards.Failuretodosomay

causeyouphysicalinjuryanddamagemotherboardcomponents.

Slot No. Slot Description

1 PCIex16_1slot

2 PCIex8_2slot

3 PCIex4slot

4 PCIex16_3slot

5 PCIex1slot

6 PCIex8/x4_4slot
