Chapter 3

3.6.5 APM Configuration

The items in this menu allow you to set system wake and sleep settings.

ErP Ready

This item allows you to switch off some power at S4+S5 or S5 to get the system ready for

ErP requirement. When set to [Enabled], all other PME options are switched off.

Conguration options: [Disabled] [Enable(S4+S5)] [Enable(S5)]

Restore On AC Power Loss

This item allows your system to go to ON state, OFF state, or both states after an AC power

loss. When setting your system to [Last State], it goes to the previous state before the AC

power loss.

Conguration options: [Power On] [Power Off] [Last State]

Power On By PCI-E/PCI

This item allows you to enable or disable the Wake-on-LAN function of the onboard LAN

controller or other installed PCI-E LAN cards.

Conguration options: [Disabled] [Enabled]

Power On By RTC

This item allows you to enable or disable the RTC (Real-Time Clock) to generate a wake

event and congure the RTC alarm date. When enabled, you can set the days, hours,

minutes, or seconds to schedule an RTC alarm date.

Conguration options: [Disabled] [Enabled]

3.6.8 Network Stack Configuration

The items in this menu allow you to enable or disable the UEFI network stack

3.6.7 Internal GOP Configuration

The items in this menu allow you to select the monitor output by Graphic Output Protocol.

SVM Mode

This item allows you enable or disable CPU Virtualization.

Conguration options: [Disabled] [Enabled]

Node 0 Information

This item allows you to view memory information related to Node 0.

3.6.6 CPU Configuration

The items in this menu show the CPU-related information that the BIOS automatically

detects.

The items in this menu may vary based on the CPU installed.
