Asus ROG ZENITH EXTREME [49/104] Cpu heatsink and fan assembly installation

ROG ZENITH EXTREME

2-3

Chapter 2

2.1.2 CPU heatsink and fan assembly installation

To install the CPU heatsink and fan assembly:

The heatsink screws are T30 models.

A torque value of 12 inch-lbf is

recommended.
