Asus ROG ZENITH EXTREME [53/104] Front i o connector

ROG ZENITH EXTREME

2-7

Chapter 2

2.1.7 Front I/O connector

USB 3.1 Gen 2

To install USB 3.1 Gen 2 connectorTo install ASUS Q-Connector

This connector will only t in one

orientation. Push the connector until it

clicks into place.

USB 2.0

AAFP

To install USB 2.0 connector

To install front panel audio connector

USB 3.1 Gen 1

To install USB 3.1 Gen 1 connector

To install system speaker connector
