1.1.9 Internal connectors
1. AMD
®
Serial ATA 6 Gb/s connectors (7-pin SATA6G_12; SATA 6G_34;
SATA 6G_56)
TheseconnectorsconnecttoSerialATA6.0Gb/sharddiskdrivesviaSerialATA6.0
Gb/ssignalcables.
IfyouinstalledSerialATAharddiskdrives,youcancreateaRAID0,1,and10
congurationthroughtheonboardAMD
®
X399chipset.
• Theseconnectorsaresetto[AHCI]bydefault.IfyouintendtocreateaSerialATA
RAIDsetusingtheseconnectors,settheSATAModeSelectionitemintheBIOSto
[RAID].
• BeforecreatingaRAIDset,refertosectionRAID configurationsorthemanual
bundledinthemotherboardsupportUSB.
• WhenusingNCQ,settheSATAModeintheBIOSto[AHCI].RefertosectionSATA
Configurationfordetails.
