ROG ZENITH EXTREME
1-27
Chapter 1
17. DIMM.2 slot (DIMM.2_SLOT)
ThissocketallowsyoutoinstallthebundledDIMM.2cardtoconnectM.2SSD
modules.
• M.2_1socketsupportsPCIe3.0x4MKeydesignandtype2230/2242/2260/2280/
22110PCIestoragedevices.
• M.2_2socketsupportsPCIe3.0x4MKeydesignandtype2230/2242/2260/2280/
22110storagedevices.
TheM.2SSDmoduleispurchasedseparately.
• BeforeyouinstallorremovetheDIMM.2card,ensurethattheATXpowersupplyis
switchedofforthepowercordisdetachedfromthepowersupply.Failuretodoso
maycauseseveredamagetothemotherboardorDIMM.2card.
• TheDIMM.2cardisnotchedtotinonlyoneorientation.Ensurethatthenotchon
yourcardisalignedcorrectlywiththeDIMM.2slotbeforeinsertingthecard.
