![Asus ROG ZENITH EXTREME [82/104] Chapter 3](/views2/1254026/page82/bg52.png)
3-18
Chapter 3: BIOS Setup
Chapter 3
3.6.10 NVMe Configuration
You may view the NVMe controller and Drive information if an NVMe device is connected.
3.6.9 HDD/SSD SMART Information
This menu displays the SMART information of the connected devices.
NVM Express devices do not support SMART information.
3.6.11 USB Configuration
The items in this menu allow you to change the USB-related features.
The Mass Storage Devices item shows the auto-detected values. If no USB device is
detected, the item shows None.
Legacy USB Support
[Enabled] Your system supports the USB devices in legacy operating systems.
[Disabled] Your USB devices can be used for BIOS setup only and cannot be
recognized in the boot devices list.
[Auto] Your system automatically detects the presence of USB devices at startup.
If any USB devices are detected, the legacy USB support is enabled.
XHCI Hand-off
[Enabled] Enables the support for operating systems without an XHCI hand-off
feature.
[Disabled] Disables the XHCI Hand-off support.
EHCI Hand-off
[Enabled] Enables the support for operating systems without an EHCI hand-off
feature.
[Disabled] Disables the EHCI Hand-off support.
USB Mass Storage Driver Support
This item allows you to enable or disable USB Mass Storage Driver Support.
Conguration options: [Disabled] [Enabled]
U31G2_E1 / U31G2_E2
These items allow you to enable or disable the individual USB ports.
Refer to section 1.1.2 Motherboard layout for the location of the USB ports.
