Asus ROG ZENITH EXTREME [24/104] Chapter 1

1-8

Chapter 1: Product Introduction

Chapter 1

• WerecommendthatyouprovidesufcientpowerwhenrunningCrossFireX™or

SLI

™mode.

• Connectchassisfanstothemotherboardchassisfanconnectorswhenusingmultiple

graphicscardsforbetterthermalenvironment.

VGA Configuration

PCI Express 3.0 operating mode

Single VGA SLI™/CFX

3-Way SLI™/

CFX

4-Way SLI™/

CFX

PCIe x16_1

x16 x16 x16 x16

PCIe x8_2

N/A N/A x8 x8

PCIe x16_3

N/A x16 x16 x16

PCIe x8/x4_4

N/A N/A N/A x8*

AMD® Ryzen™ Threadripper™ Processors

* The PCIE_X8/X4_4 slot shares bandwidth with U.2. In 4-Way configuration, if the PCIE_X8/X4_4 is used in x8

mode, U.2 port will be disabled.
