Asus ROG ZENITH EXTREME [47/104] Chapter 2 basic installation

ROG ZENITH EXTREME

2-1

Chapter 2

Basic Installation

2.1 Building your PC system

The diagrams in this section are for reference only. The motherboard layout may vary with

models, but the installation steps are the same for all models.

Chapter 2: Basic Installation

2.1.1 CPU installation

The AMD® TR4 socket is compatible with AMD® TR4 processors. Ensure you use a CPU

designed for the TR4 socket. The CPU ts in only one correct orientation. DO NOT force

the CPU into the socket to prevent bending the connectors on the socket and damaging

the CPU!

Rail frame

External cap

Carrier frame

with CPU

PnP cap

Load plate

Rail frame
