Asus ROG ZENITH EXTREME [52/104] Atx power connection

2-6

Chapter 2: Basic Installation

Chapter 2

2.1.5 ATX power connection

Ensure to connect both 8-pin power plugs.

2.1.6 SATA device connection

AND
