ROG ZENITH EXTREME
1-19
Chapter 1
5. USB 2.0 connector (10-1 pin USB1314)
ThisconnectorisforUSB2.0ports.ConnecttheUSBmodulecabletothisconnector,
theninstallthemoduletoaslotopeningatthebackofthesystemchassis.ThisUSB
connectorcomplieswithUSB2.0specicationthatsupportsupto480Mb/sconnection
speed.
Neverconnecta1394cabletotheUSBconnectors.Doingsowilldamagethe
motherboard!
1xUSB2.0port(USB1314)atmid-boardshareswithROGextension(ROG_EXT)port.
6. Thermal sensor connectors (2-pin T_SENSOR1-2)
Theseconnectorsareforthethermistorcablesthatmonitorthetemperatureofthe
devicesandthecriticalcomponentsinsidethemotherboard.Connectthethermistor
cableandplacethesensoronthedeviceorthemotherboard’scomponenttodetectits
temperature.
