Asus ROG ZENITH EXTREME [78/104] Chapter 3

3-14

Chapter 3: BIOS Setup

Chapter 3

Custom CPU Core Ratio

This item allows you to set a custom CPU core ratio. The CPU core ratio is calculated with

the formula: 2 * FID / DID.

Conguration options: [Auto] [Manual]

The following item appears only when you set the Custom CPU Core Ratio to [Manual].

FID

This item allows you to set the core frequency multiplier. Use the <+> or <-> to adjust

the value.

DID

This item allows you to set the core frequency divisor. Use the <+> or <-> to adjust the

value.

Memory Frequency

This item allows you to set the memory operating frequency. The congurable options vary

with the BCLK (base clock) frequency setting. Select the auto mode to apply the optimized

setting.

Conguration options: [Auto] [DDR4-1333MHz] - [DDR4-4000MHz]

3.6 Advanced menu

The Advanced menu items allow you to change the settings for the CPU and other system

devices.

Be cautious when changing the settings of the Advanced menu items. Incorrect eld values

can cause the system to malfunction.

3.6.1 AMD fTPM configuration

The items in this menu show the AMD fTPM conguration options.

TPM Device Selection

This item allows you to select the TPM device.

[Firmware TPM] Enables AMD CPU fTPM.

[Discrete TPM] Disables AMD CPU fTPM.

3.6.2 ROG Effects

The items in this menu allow you to congure the LEDs on your motherboard.

Onboard LED

This item allows you to enable all the onboard LEDs.

Conguration options: [Enabled] [Disabled]
