Chapter 2: Basic Installation

Chapter 2

Apply the Thermal Interface Material

to the CPU heatsink and CPU before

you install the heatsink and fan if

necessary.

The load plate screws are T30

models. A torque value of 12 inch-lbf

is recommended.

Carrier frame

with CPU
