Chapter 2: Basic Installation

Chapter 2

* LAN ports LED indications

** Audio 2, 4, 6 or 8-channel configuration

SPEED

LED

ACT/LINK

LED

LAN port

Activity Link LED Speed LED

Status Description Status Description

OFF No link OFF 10 Mbps connection

ORANGE Linked ORANGE 100 Mbps connection

BLINKING Data activity GREEN 1 Gbps connection

Port

Headset

2-channel

4-channel 6-channel 8-channel

Light Blue Line In Line In Line In

Side Speaker Out

Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out

Red

Mic In Mic In Mic In Mic In

Orange – –

Center/Sub

woofer

Center/Sub

woofer

White

– Rear Speaker Out Rear Speaker Out Rear Speaker Out
