![OKI MB441 [139/198] Cause remedy](/views2/1029545/page139/bg8b.png)
Error Messages
-139-
Troubleshooting
7
Disk Use Failed %FS_ERR%
Please see Help for details.
to Close
Blinks A disk operation error has occurred.
Please check data.
Message Data Write Error : %CODE%.
Lights up Failure to write message data to be uploaded.
Contact your dealer.
Please check %COLOR% Toner Cartridge.
Please see Help for details.
Lights up Something is wrong with the toner sensor of the
indicated color during printing.
Check that the toner cartridge of the indicated
color is installed properly.
543 Please check %COLOR% Toner Cartridge. :
%ERRCODE%
Please see Help for details.
Blinks Something is wrong with the toner sensor of the
indicated color.
Check that the toner cartridge of the indicated
color is installed properly.
543 : K
547 Please check %COLOR% Toner Cartridge. :
%ERRCODE%
Please see Help for details.
Blinks The toner cartridge of the indicated color is not
locked properly.
Check that the lock lever is properly slid to the
left.
547 : K
372
380
381
382
389
390
Paper Jam: %ERRCODE%
Please open the scanner unit and the top
cover.
Please see Help for details.
Blinks Paper jam has occurred.
Remove the jammed paper.
Error 372 : Misfeed from Duplex
Error 380 : Paper Feed
Error 381 : Transport
Error 382 : Exit
Error 389 : Printing Page Lost
Error 390 : MP Tray
Error 390 : MANUAL
391
392
Paper Jam: %ERRCODE%
Please pull out the paper cassette of the
indicated tray.
Please see Help for details.
Blinks Paper jam occurred while feeding paper from the
indicated tray.
Remove the jammed paper.
391 : Tray1
392 : Tray2
310
587
Please check the %COVER%.: %ERRCODE%
Please close the %COVER%.
Please see Help for details.
Blinks The top cover is open.
Close the top cover.
310 : Top Cover
587 : Rear Cover
ADF Cover Open
Please see Help for details.
Blinks The ADF cover is open.
Close the ADF cover.
Power OFF/ON
%ERRCODE%: Error
Blinks An error has occurred in the device.
Turn the machine off and then on again.
If the error is not resolved, contact your dealer.
Inspection is required.
%ERRCODE: Error
Blinks An error has occurred in the device.
Contact your dealer.
Error
code
Message
<Status>
key
Cause/Remedy
OK
