Specifications (MB441/MB451/MB451w)
-185-
Appendix
9
Copier Specifications
Fax Specifications
PC Fax Specifications
Internet Fax Specifications
MB441 MB451 MB451w
Document
size
ADF
A6 , B5 , A5 , A4 , letter , legal 13/13.5/14, executive
Document
glass
A6 , B5 , A5 , A4 , letter , executive
First copy
Time
Mono 10 seconds or less (ADF,
High Speed)
10 seconds or less (ADF,
High Speed)
10 seconds or less (ADF,
High Speed)
Copies Up to 99
MB441 MB451 MB451w
Compatibility - ITU-T G3/Super G3
Compression method - MH, MR, MMR, JBIG
Modem speed - Up to 33.6 Kbps
Lines - PSTN, PBX Line
Line interface - RJ11 x 2 (Line/TEL)
Document
size
ADF - A4, letter, legal 13/13.5/14
Document
glass
- A4, letter
Transmission speed - Approx. 3 seconds/page (ITU-T, MMR, Normal)
Stored document
memory size
-4 MB
Storage document
capacity
- Up to 200 pages (ITU-T no.1, MMR, Normal)
Resolution - Normal
8 dots x 3.85 line/mm
Fine
8 dots x 7.7 line/mm
8 dots x 7.7 line/mm
Extra-Fine
8 dots x 15.4 line/mm
MB441 MB451 MB451w
Interface - USB 2.0 (Hi-Speed), Ether-
net 10BASE-T/100BASE-TX
USB 2.0 (Hi-Speed), Ether-
net 10BASE-T/100BASE-TX,
IEEE820.11 b/g/n Wireless
LAN
Supported OS - Windows 7, Windows Vista, Windows Server 2008 R2,
Windows Server 2008, Windows XP, Windows Server 2003
MB441 MB451 MB451w
Communication
protocol
- SMTP, POP3, MIME
File format TIFF - TIFF
