Specifications (MB461/MB471/MB471w/MB491/ES4161 MFP/ES4191 MFP)
-183-
Appendix
9
Network Specifications
Wireless LAN Specifications
MB461/
ES4161 MFP
MB471 MB471w
MB491/
ES4191 MFP
Interface Ethernet 10BASE-T/100BASE-TX Ethernet 10BASE-T/
100BASE-TX,
IEEE820.11 b/g/n
Wireless LAN
Ethernet 10BASE-T/
100BASE-TX
Protocol TCP/IPv4, TCP/IPv6, NetBEUI, NetBIOS
over TCP, EtherTalk, NetWare, LPR,
Port9100, IPP, FTP, HTTP, TELNET, SMTP,
POP3, SNMPv1/v3, DHCP, BOOTP, DNS,
DDNS, UPnP, WINS, SLP, Bonjour
(Rendezvous), SNTP, LLTD, Web Services
Discovery (WSD), SSL/TLS, IPSec, CIFS,
SMB (Version 1.0), LDAPv3, Kerberos
TCP/IPv4, TCP/IPv6,
NetBEUI, NetBIOS
over TCP, EtherTalk,
NetWare, LPR,
Port9100, IPP, FTP,
HTTP, TELNET, SMTP,
POP3, SNMPv1/v3,
DHCP, BOOTP, DNS,
DDNS, UPnP, WINS,
SLP, Bonjour
(Rendezvous), SNTP,
LLTD, Web Services
Discovery (WSD),
SSL/TLS, IPSec, CIFS,
SMB (Version 1.0),
LDAPv3, Kerberos,
IEEE820.11 b/g/n,
Infrastructure Mode,
WEP, WPA(TKIP/AES),
WPS-PCB/WPS-PIN,
Open system
authentication,
IEEE802.1x
authentication
TCP/IPv4, TCP/IPv6,
NetBEUI, NetBIOS
over TCP, EtherTalk,
NetWare, LPR,
Port9100, IPP, FTP,
HTTP, TELNET, SMTP,
POP3, SNMPv1/v3,
DHCP, BOOTP, DNS,
DDNS, UPnP, WINS,
SLP, Bonjour
(Rendezvous), SNTP,
LLTD, Web Services
Discovery (WSD),
SSL/TLS, IPSec,
CIFS, SMB (Version
1.0), LDAPv3,
Kerberos
Supported browsers Microsoft IE 6.0 or later, Safari 2.0 or later, Firefox 3.0 or later
MB461/
ES4161 MFP
MB471 MB471w
MB491/
ES4191 MFP
Wireless LAN adapter - OkiLAN520w -
Wireless LAN
standard
- IEEE 802.11b/g/n
conformity (2.4GHz)
-
Transfer rate - 11n technology:
Max150Mbps
IEEE802.11g:
Max54Mbps
IEEE802.11b:
Max11Mbps
-
Antenna system - Built-in Antenna
1T1R
-
LAN protocol - TCP/IP (IPv6/IPv4) -
Security - WEP(128/
64bit),WPA,WPA2,IE
EE802.1x wireless
securities.
-
