Loading Paper and Documents
-30-
Paper Type Paper Size mm (inch) Paper Weight
Envelope Monarch 98.4 x 190.5
(3.875 x 7.5)
Envelopes should be 88 g/m
2
(24lb)
paper, and flap parts of envelopes should
be folded
Com-9 98.4 x 225.4
(3.875 x 8.875)
Com-10 104.8 x 241.3
(4.125 x 9.5)
DL 110 x 220
(4.33 x 8.66)
C5 162 x 229
(6.4 x 9)
Index card Index card 76.2 x 127.0
(3 x 5)
Label A4 210 x 297 0.1~0.2 mm
Letter 215.9 x 279.4
(8.5 x 11)
Partly-printing
paper
Subject to the standard paper
64 to 163 g/m
2
(18 to 43lb)
Color paper Subject to the standard paper
64 to 163 g/m
2
(18 to 43lb)
