Specifications (MB441/MB451/MB451w)
-186-
Scanner Specifications
Scan To E-mail Specifications
Scan To Network PC Specifications
Scan To USB Memory Specifications
MB441 MB451 MB451w
Scanner type Document Glass with ADF function
Image sensor Color CIS
Light source LED
Document
thickness
ADF
60 to 105 g/m
2
(16 to 28 lb)
Document
glass
20 mm
ADF document
capacity
50 sheets (80 g/m
2
)
Scanning
area
ADF 105 x 148 - 215.9 x 355.6 mm (4.13 x 5.8 - 8.5 x 14 inches)
Document
glass
105 x 148 - 215.9 x 296.9 mm (4.13 x 5.8 - 8.5 x 11.69 inches)
Scanning
speed
Color Approx. 6 seconds/page (A4, 300 x 300 dpi, ADF simplex)
Mono Approx. 2 seconds/page (A4, 300 x 300 dpi, ADF simplex)
MB441 MB451 MB451w
Communication
protocol
SMTP, POP3, MIME
File format PDF (supported Encryption), M-TIFF (RAW/G3/G4 compressed), JPEG (JFIF) (color/
grayscale only), XPS
Mail server
authentication
SMTP-AUTH, POP3
Supported mail
server application
Lotus Domino Mail Server 5.0, Microsoft Exchange 2000 Server, Microsoft Exchange 2003
Server, Microsoft Exchange 2007 Server, Red Hat 7.0 Sendmail
Supported LDAP
server
Windows Server 2008 Active Directory, Windows Server 2003 ActiveDirectory, Windows
2000 Server Active Directory, Lotus Notes/Domino 7.0
Supported mail
application
Microsoft Office Outlook 2000, Microsoft Outlook Express 5.0/6.0, Windows Mail
(Windows Vista), Windows Live Mail, Mail (MAC built-in application), Lotus Notes/Domino
R5
MB441 MB451 MB451w
Communication
protocol
FTP, HTTP, CIFS
File format PDF (supported Encryption), M-TIFF (RAW/G3/G4 compressed), JPEG (JFIF) (color/
grayscale only), XPS
MB441 MB451 MB451w
Connectivity interface USB2.0 Host IF
Storage device USB memory (Up to 32 GB)
Not all USB memory products are guaranteed to work.
Supported file system FAT12, FAT (FAT16), FAT32
File format PDF (supported Encryption), M-TIFF (RAW/G3/G4 compressed), JPEG (JFIF) (color/
grayscale only), XPS
