OKI MB451 [39/198] Close the document glass cover gently
![OKI MB441 [39/198] Close the document glass cover gently](/views2/1029545/page39/bg27.png)
Loading Paper and Documents
-39-
Setup
1
If your document is landscape, align its right edge
to the upper-left corner of the glass.
3 Close the document glass cover gently.
Reference
Set [Document Direction] according to the direction of
your document to get the output you want. The factory
default is [Portrait]. Refer to "Changing Image
Orientation of Document (Direction)" P. 80.
Note
When you take a copy with the document glass, do not
apply an excessive load to the document glass.
