OKI MB451 [180/198] Printing specifications
![OKI MB451 [180/198] Printing specifications](/views2/1029545/page180/bgb4.png)
Specifications (MB461/MB471/MB471w/MB491/ES4161 MFP/ES4191 MFP)
-180-
Scan To Network PC Specifications
Scan To USB Memory Specifications
Scan To Local PC Specifications
Printing Specifications
Supported mail
application
Microsoft Office Outlook 2000, Microsoft Outlook Express 5.0/6.0, Windows Mail
(Windows Vista), Windows Live Mail, Mail (MAC built-in application), Lotus Notes/Domino
R5
MB461/
ES4161 MFP
MB471 MB471w
MB491/
ES4191 MFP
Communication
protocol
FTP, HTTP, CIFS
File format PDF (supported Encryption), M-TIFF (RAW/G3/G4 compressed), JPEG (JFIF) (color/
grayscale only), XPS
MB461/
ES4161 MFP
MB471 MB471w
MB491/
ES4191 MFP
Connectivity interface USB2.0 Host IF
Storage device USB memory (Up to 32 GB)
Not all USB memory products are guaranteed to work.
Supported file system FAT12, FAT (FAT16), FAT32
File format PDF (supported Encryption), M-TIFF (RAW/G3/G4 compressed), JPEG (JFIF) (color/
grayscale only), XPS
MB461/
ES4161 MFP
MB471 MB471w
MB491/
ES4191 MFP
Communication
protocol
Windows TWAIN, WIA
Mac OS X TWAIN, ICA
File format PDF, TIFF, JPEG, BMP, PCX, GIF, TGA, PNG, WMF, EMF
MB461/
ES4161 MFP
MB471 MB471w
MB491/
ES4191 MFP
Printing method Dry electrophotographic recording method with LED (Light-emitting diode)
Emulation T PCL6 (PCLXL), PCL5e PCL6 (PCLXL), PCL5e, PostScript 3
Resident fonts PCL: 91 European
fonts
PCL: 91 European fonts
PS: 136 European fonts
Resolution 600 x 600 dpi,
600 x 1200 dpi,
600 x 2400dpi
600 x 600 dpi, 1200 x 1200 dpi 600 x 600 dpi,
1200 x 1200 dpi
Color black
MB461/
ES4161 MFP
MB471 MB471w
MB491/
ES4191 MFP
