Installing Options
-24-
5 If the optional tray is already mounted,
click [Second Tray], and then click [OK].
For Mac OS X PCL/PS Driver
(Mac OS X 10.4.0 to 10.4.11)
Memo
The following procedure uses Mac OS X 10.4.11 as an
example. Depending on an OS, the description may be
different.
1 From [Go], select [Utilities] and then
double-click [Printer Setup Utility].
2 Select the name of your machine and
then click [Show Info].
3 Select [Installable Options].
4 If the optional tray is already mounted,
click [Second Tray], and then click
[Apply Changes].
5 Close [Printer Info].
