Other Issues
-154-
Restrictions on Mac OS X 10.6
Restrictions on Mac OS X 10.5
Restrictions on Mac OS X 10.4
Web Driver
Installer
Unable to access the machine from a remote
computer.
Click [start] and then select [Operator
panel] > [Security Center] > [Windows
Firewall].
Select the [Exception] tab and click [Add
Port]. Add the port number of the web site on
which Driver Installer is installed.
Click [start] and then select [Operator
panel] > [Performance and Maintenance]
> [Administrative Tools].
Double-click [Component Services] and
change the access authority of the component
for Driver Installer.
For details on how to configure the settings,
refer to the readme file stored in [start] > [All
Programs] > [Okidata] > [Driver Installer]
> [Readme].
Item Symptom Cause/Remedy
TWAIN driver Unable to scan by image capture. Scan is available only when the computer is
connected by USB.
In the image capture, the user interface of
the TWAIN driver is not displayed. Use the
user interface of the image capture and
then scan data.
Item Symptom Cause/Remedy
TWAIN driver Unable to scan by image capture. In the image capture, if the computer is con-
nected to the network, display the user inter-
face of the TWAIN driver before using.
To display the user interface of the TWAIN
driver, after starting the image capture, select
[Browse Devices] from the [Devices] menu
of the image capture and then open the
device browser. Select a driver and click use
[Use TWAIN UI].
Item Symptom Cause/Remedy
TWAIN driver Unable to scan by image capture In the image capture, if the computer is con-
nected to the network, display the user inter-
face of the TWAIN driver before using.
To display the user interface of the TWAIN
driver, after starting the image capture, select
[Browse Devices] from the [Devices] menu
of the image capture. Select a driver in
[TWAIN devices] and then check the check-
box of [Use TWAIN software] shown in the
lower right screen.
Item Symptom Cause/Remedy
