Configuring the Network Settings
-73-
Setup
1
For Mac OS X 10.5 to 10.7
1 From the Apple menu, select [System
Preferences].
2 Click [Users & Groups] (for Mac OS X
10.5 and 10.6: [Accounts]).
3 Click [Click the lock to make
changes.] at the bottom left of the
screen and enter the administrator
password. Then, click [Unlock] (for Mac
OS X 10.5 and 10.6: [OK]).
4 Click [+].
5 Select [Standard] from [New
Account].
6 Enter the value of C-2 in [Name].
For Mac OS X 10.5, enter the value of C-2 in
[Name].
7 Enter the value in C-3 in both
[Password] and [Verify].
8 Click [Create User] (for Mac OS X 10.5
and 10.6: [Create Account]).
Memo
After the dialog box for auto login appears, disable the
auto login.
9 Check that an account is added to
[Other Users] (for Mac OS X 10.5 and
10.6: [Other Accounts]) with the name
of C-2, and close [Users & Groups] (for
Mac OS X 10.5 and 10.6: [Accounts]) .
10 Create a new folder on the computer
with the name entered in C-5.
11 From the Apple menu, select [System
Preferences].
12 Click [Sharing].
13 Check the check box of [File Sharing].
14 Click [+] under [Shared Folder].
15 Select the folder created in step 10 and
click [Add].
16 Select the folder added in step 15 and
click [+] under [Users].
