Connecting to a Computer
-54-
Memo
If the machine is not displayed by clicking [Restart
search], select [Printer name/IP Address] and
enter the IP address assigned to your machine, and
then click [Next].
11 If the [Windows Security] dialog box
appears, click [Install this driver
software anyway].
12 Click the [Exit] button.
13 Remove the "Software DVD-ROM" from
the computer.
The installation is complete.
Print a test page to check that the printer
driver is successfully installed on the
computer.
1 Click [Start] > [Devices and Printers].
2 Right-click the OKI MB491 icon and
select [Printer properties] (> a desired
printer driver if you have installed
multiple drivers) from the pop-up menu.
3 On the [General] tab, click [Print Test
Page].
Installing a Printer Driver
(For Mac OS X)
To complete the network connection with a Mac
operating system, install a printer driver on the
computer and set your machine as a network
printer.
Select the protocol for your network connection
from the following:
EtherTalk
Bonjour
Note
EtherTalk is not supported in Mac OS X 10.6 or later.
Disable the anti-virus software before starting this
procedure.
EtherTalk is not supported in Mac PCL.
Using EtherTalk (For Mac OS X
10.5)
When connecting to the network with EtherTalk,
it is necessary to enable EtherTalk in the
machine. Then, install the driver in the computer.
First, enable EtherTalk in the machine.
1 Ensure that your machine and the
computer are turned on and connected.
Reference
"Connecting an Ethernet Cable" P. 47
2 Press the <SETTING> key on the
operator panel.
3 Press the to select [Admin Setup],
and press .
4 Enter the administrator password.
The factory default password is "aaaaaa".
5 Select [Complete], and press .
6 Press the to select [Network Menu],
and press .
7 Press the to select [Network Setup],
and press .
8 Press the to select [EtherTalk], and
press .
9 Press the to select [Enable], and
press .
10 Press the until the top screen is
displayed.
OK
OK
OK
OK
OK
OK
