![OKI MB441 [177/198] Appendix](/views2/1029545/page177/bgb1.png)
-177-
Appendix
9
9. Appendix
This chapter explains the specifications of your machine and information on consumables and optional
components.
Specifications (MB461/MB471/MB471w/MB491/
ES4161 MFP/ES4191 MFP)
General Specifications
MFP Model Model Number
MB461/ES4161 MFP N22205A, N22205B
MB471 N22206A, N22206B
MB471w N22207A, N22207B
MB491/ES4191 MFP N22208A, N22208B
MB461/
ES4161 MFP
MB471 MB471w
MB491/
ES4191 MFP
CPU Printer controller
PowerPC405 , 330 MHz
Scanner controller
ARM9 max 266 MHz
Memory Resident Printer controller
256 MB
Scanner controller
128 MB
Flash
ROM
Printer
Controller
SPI ROM : 16MB x 2
Scanner
Controller
NAND : 64 MB
SPI : 2 MB
Storage Device - SD memory card
Resident
4 GB
Weight 20 kg (including consumables)
Dimensions 427 (W) x 425 (D) x 455 (H)
Power supply N22205A, N22206A, N22207A, N22208A: 120VAC ±10% , 50/60Hz ±2%
N22205B, N22206B, N22207B, N22208B: 220V AC ±10%, 50/60Hz ±2%
Power consumption Typical operation
540 W
Idle
80 W
Peak
950 W
Sleep mode
Less than 3 W
Power save mode
Less than 14 W
Off mode
Less than 0.5 W
Typical operation
580 W
Idle
80 W
Peak
950 W
Sleep mode
Less than 3 W
Power save mode
Less than 14 W
Off mode
Less than 0.5 W
Typical operation
580 W
Idle
80 W
Peak
950 W
Sleep mode
Less than 3 W
Power save mode
18 W
Off mode
Less than 0.5 W
Typical operation
610 W
Idle
80 W
Peak
950 W
Sleep mode
Less than 3 W
Power save mode
Less than 14 W
Off mode
Less than 0.5 W
Operating condition Operating
Temperature : 10 to 32°C, humidity : 20 to 80% RH
Idle
T
emperature : 0 to 43°C, humidity : 10 to 90% RH
