15
• Do not use any cleaning agents or solvents, they may damage
plastic parts.
• Clean ventilation holes in the motor casing regularly to
prevent device overheating.
• In case of excessive commutator sparking, have the technical
condition of carbon brushes of the motor checked by a
qualified person.
• Always store the tool in a dry place, beyond reach of children.
• Store the device with the battery removed.
QUICK RELEASE CHUCK REPLACEMENT
Quick-release chuck is screwed onto spindle of the drill and
additionally secured with a screw.
• Set the direction selector switch (5) in the middle position.
• Open jaws of quick release chuck (1) and unscrew the fixing
screw (left-hand thread) (fig. H).
• Install hexagonal key in the quick release chuck and tap the
other end of the key.
• Unscrew the quick release chuck.
• Installation of the quick release chuck is similar to
deinstallation, only the sequence of actions is reversed.
All defects should be repaired by service workshop authorized
by the manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Cordless drill with impact
Parameter Value
Battery voltage 18 V DC
Range of idle rotational speed
gear I 0-350 min
-1
gear II 0-1250 min
-1
Impact speed on idle
gear I 0-5250 min
-1
gear II 0-18750 min
-1
Range of quick release chuck 2-13 mm
Torque control range
1–16 + drilling,
impact drilling
Max. torque (soft drive) 35 Nm
Max. torque (hard drive) 55 Nm
Protection class III
Weight 1,3 kg
Year of production 2017
Graphite Energy+ System Battery
Parameter Value
Battery 58G001 58G004
Battery voltage 18 V DC 18 V DC
Battery type Li-Ion Li-Ion
Battery capacity 2000 mAh 4000 mAh
Ambient temperature range 4
0
C – 40
0
C4
0
C – 40
0
C
Charging time for charger 58G002 1 h 2 h
Weight 0,400 kg 0,650 kg
Year of production 2017 2017
Graphite Energy+ System Charger
Parameter Value
Charger type
58G002
Supply voltage
230 V AC
Power supply frequency
50 Hz
Charging voltage
22 V DC
Max. charging current
2300 mA
Ambient temperature range
4
0
C – 40
0
C
Charging time of the battery 58G001
1 h
Charging time of the battery 58G004
2 h
Protection class
II
Weight
0,300 kg
Year of production
2017
NOISE LEVEL AND VIBRATION PARAMETERS
Noise and vibration information
Parameters of produced noise level, such as sound pressure level
Lp
A
and sound power level Lw
A
with measurement uncertainty K
are specified below in this manual, in compliance with EN 60745.
Vibration values a
h
and measurement uncertainty K are
determined in accordance with EN 60745-2-1 and specified
below.
Vibration level specified below in this manual was measured in
accordance with measurement procedure defined in EN 60745
and can be used to compare power tools. It can also be used for
initial assessment of exposure to vibrations.
Specified vibration level is representative for main applications
of the power tool. Vibration level may change if the power tool is
used for other purposes, with different working tools or will not
be maintained properly. The abovementioned factors may lead
to higher exposure to vibrations during whole working time.
To precisely define exposure to vibrations, include periods when
the power tool is switched off and when it is switched on but
not used for working. This way total exposure to vibrations may
be significantly lower. Use additional safety measures to protect
the user against results of exposure to vibrations, such as: power
tool and working tool maintenance, proper hand temperature
conditions, good work organisation.
Sound pressure level: Lp
A = 84 dB (A) K=3dB (A)
Sound power level: Lw
A = 95 dB (A) K=3dB (A)
Vibration acceleration: a
h = 7,528 m/s
2
K = 1,5 m/s
2
ENVIRONMENTAL PROTECTION / CE
Electrical equipment must not be disposed off
with household waste and, instead, should be
utilized at appropriate facilities. Information
on utilization can be provided by the product
vendor or the local authorities. Waste electrical
and electronic equipment contains substances
that are not neutral to the natural environment.
Equipment that is not recycled constitutes a
potential hazard to the environment and to
human health.
Li-Ion
Storage batteries/batteries must not be disposed
with domestic waste, put in a fire or into the
water. Damaged or used up storage batteries
must be properly recycled in compliance with the
current directive pertaining to disposal of storage
batteries and batteries.
* Right to introduce changes is reserved.
